38
Regulator, Handle, and Hood
Assemblies Continued
Ref.Part # Description Qty.
1 MP042000 BAIL, PAINTED 1
2 MP106500 CABLE, THROTTLE, CONTROL 1
3 NB4382 SCREW, DRILL KWIK, 8 x 1/2 5
4 MP050500 BLOCK, GUIDE, CABLE, THROTTLE 1
5 NB028300 BUSHING, CABLE, BAIL 1
6 NB9645 WASHER, FLAT, #10 2
7 NB9735 NUT, LOCK, 10-24, NYLON 1
8 NB049100 SCREW, BH, 10-24 X 7/8, SS 1
020211
Handle
Hood
Regulator
Ref.Part # Description Qty.
9 MP375800 HOOD, BULKHEAD, BLACK, ASM. 1
10 MP075200 FOAM, SKINNED, 1/2 X 38 X 1/4 THK 1
11 MP373400 FILTER, AIR, HOOD, BULKHEAD 1
Ref.Part # Description Qty.
12 MP245100 REGULATOR, BEAM, T60 1
13 MP017900 FUEL, ADJUSTMENT, ASSEMBLY 1
14 MP019500 HOSE, BARB, 1/8 NPT, 1/4 BARB 1
15 MP027100 FITTING, EXTENSION, 1/4 X 1/4 NPT1
16 MP317500 FUELOCK, 12 VOLT, ASM. 1
17 MP4330 FITTING, 49 X 6, REG TO FUELOCK 1
18 MP027200 FITTING, 90DEG. ELBOW, 1/4 X 1/4
NPT 1
19 MP371100 FITTING, BRASS, 1/4-28 x 3/16” HB 1
