Pioneer PDP-42MVE1 Service Manual

99
13. BACK COVER(modification)
(2)FRONT PANEL ASSY
(1)SRW25 PTN3*12*15
KFE 29N01491 *6p
(Caution) The illustration below shows a case when the STAND has been removed.
(Caution) The FRONT PANEL can be taken
out when this screw only has been.
(2)M40 BRACKET OPTION
L29H02353
(
(1)SRW10 CBIPS*4*12*15
KFE 29N01401*2p
(6)CONNECTOR11p
(5) SRW14 TP-3*6*3KF
24N04581 5p
(3)SRW08 CBIPS*3*8*3KF
24N03691*4p
(4) M37SHIELD COVER
MAIN 29H03571
14. TERMINAL PANEL M SUB ASSY
(7) SRW04 CBIPS*3*8*3KF
24N 036912p
(8) SRW24 PTN3*12*15
KFE 29N01491 3p
(9)SRW27 P-CPIMS*3*6*
3KF 29N01201
10-9
