Pioneer PDP-434PU User Manual

PDP-434PU
21
5 678
56
7
8
C
D
F
A
B
E
FRONT PANEL SECTION Parts list
(2) CONTRAST TABLE
PDP-434PU/ TUCK, PDP-434PE/ WYVI6, PDP-434PE/ WYVI6XK and PRO-434PU/ KUC are constructed the
same except for the following :
2.8 PDP SERVICE Assy (AWU1079)
PDP SERVICE Assy (AWU1079) Parts list
2.9 PANEL CHASSIS (43) Assy (AWU1070)
PANEL CHASSIS (43) Assy (AWU1070) Parts list
Mark
No. Description Part No.
1PANEL LED Assy AWZ6787
2PANEL KEY Assy AWZ6788
3Panel Cushion V (43) AED1201
4Panel Cushion H (43) AED1200
5 Protect Panel Assy 43 See Contrast table (2)
NSP 6 Panel Holder (43) ANG2552
7 Cushion AEB1393
8Front Case Assy See Contrast table (2)
9Power Button See Contrast table (2)
10 Coil Spring ABH1114
11 Blind Cushion AEB1383
12 Screw BBZ30P050FMC
13 Screw ABZ30P060FMC
14 Serial Sheet AAX2609
15 Screw APZ30P080FZK
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-434PU
TUCK
PDP-434PE
WYVI6
PDP-434PE
WYVI6XK
PRO-434PU
KUC
5 Protect Panel Assy (43) AMR3383 AMR3345 AMR3345 AMR3345
8Front Case Assy AMB2779 AMB2779 AMB2779 AMB2783
9Power Button AAD4123 AAD4123 AAD4123 AAD4126
Mark
No. Description Part No.
NSP 1..P. Chassis (43) Assy AWU1070
NSP 2..Front Chassis H (43) ANA1714
2..Front Chassis VL (43) ANA1762
2..Front Chassis VR (43) ANA1763
2..Sub Frame L Assy ANG2545
2..Sub Frame R Assy ANG2548
2..Wire Saddle AEC1745
2..Clamp AEC1884
2..PCB Support AEC1938
2..PCB Spacer AEC1941
2..PCB Spacer AEC1947
2..Wire Clip AEC1948
2..Ferrite Clamp (Plastic) AEC1972
2..Panel Cushion H (43) AED1200
2..Panel Cushion V (43) AED1201
2..Ydrive Protect Sheet AMR3346
2..Front Spacer AMR3369
2..Caution Label AAX3031
2..Spacer AEB1397
2..Edging Saddle AEC1737
NSP 2..Drive Voltage Label ARW1097
2..Front Case (434 Service) AMB2810 (Note)
2..Rear Case (43P) ANE1612 (Note)
Note: The front case (434 Service) and rear case (434p) attached
to the Service Assy are for transportation only.
Do NOT use them as parts of the unit.
2..Screw AMZ30P060FZK
2..Screw AMZ30P080FMC
2..Screw AMZ30P080FZK
2..Screw PMB30P060FNI
2..Screw VBB30P080FNI
2..Screw ABZ30P100FZK
Mark No. Description Part No.
Mark No. Description Part No.
NSP 1..43 ADDRESS Assy AWV2020
NSP 2..43 ADDRESS Assy AWZ6793
NSP 1..43 SCAN FUKUGO Assy AWV2023
NSP 2..43 SCAN A Assy AWZ6796
NSP 2..43 SCAN B Assy AWZ6797
NSP 2..X CONNECTOR A Assy AWZ6798
NSP 2..X CONNECTOR B Assy AWZ6799
NSP 1..Address Module (IC1-IC32) AXF1115
NSP 1..Plasma Panel Assy (43")(V1) AAV1243
NSP 1..FPC (43XGA-X) ADY1079
NSP 1..FPC (43XGA-Y) ADY1080
NSP 1..Chassis Assy (43) ANA1733
1..PCB Spacer AEC1944
1..PCB Support AEC1958
1..Rivet (Plastic) AMR1066
1..FC Spacer AMR3370
1..Adhesive ZBA-KE3424G
NSP 1..Lotion ZLX-AP7
NSP 1..Tape ZTA-8101-12
NSP 1..Double Faced Tape ZTB-5015-18
NSP 1..Tape ZTC-POLYCA-11
NSP 1..Tape ZTC-POLYCA-20
NSP 1..Tape ZTC-900UL-15
NSP 1..Silicone Rubber ZTX-HC20-15
NSP 1..Wiping Cloth ZTX-MX100-13
NSP 1..Film ZTX-2102Y35-2R5
NSP 1..Film ZTX-2102Y45-5
Mark
No. Description Part No.
