PDP-434PU
39
5 678
56
7
8
C
D
F
A
B
E
5. PCB PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560
47k
0.5
1
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k
RN1/4PC F562 x 10
1
5621
Mark No. Description Part No.
LIST OF ASSEMBLIES
NSP 1..43 ADDRESS ASSY AWV2020
NSP 2..43 ADDRESS ASSY AWZ6793
NSP 1..43 SCAN FUKUGO ASSY AWV2023
NSP 2..43 SCAN A ASSY AWZ6796
NSP 2..43 SCAN B ASSY AWZ6797
NSP 2..X CONNECTOR A ASSY AWZ6798
NSP 2..X CONNECTOR B ASSY AWZ6799
NSP 1..HD FUKUGO ASSY AWV2017
2..PANEL IF ASSY AWZ6786
2..PANEL LED ASSY AWZ6787
2..PANEL KEY ASSY AWZ6788
2..KEY CONTROL ASSY AWZ6789
2..PANEL IR ASSY AWZ6790
NSP 1..DIGITAL VIDEO ASSY AWV2070
1..HD AUDIO ASSY AWV2019
2..HD SP TERMINAL ASSY AWZ6792
2..HD AUDIO AMP ASSY AWZ6834
NSP 1..43 X DRIVE ASSY AWV2021
2..43 X DRIVE ASSY AWZ6794
2..PANEL SENSOR ASSY AWZ6795
1..43 Y DRIVE ASSY AWV2022
>
1..POWER SUPPLY UNIT AXY1068
Mark No. Description Part No.
43 ADDRESS ASSY
[ADR LOGIC BLOCK]
SEMICONDUCTORS
IC1501 PEE001B
COILS AND FILTERS
F1501-F1503 ATF1194
CAPACITORS
C1556,C1559,C1560,C1563 ACG1105
(330p/100V)
C1501,C1502 (47/6.3V) ACH1357
C1503-C1507,C1555 CKSSYF104Z16
C1558,C1561,C1564 CKSSYF104Z16
RESISTORS
R1510,R1519,R1522 RAB4C470J
R1505-R1509 RS1/16SS1000F
Other Resistors RS1/16S###J
OTHERS
CN1501 40P FFC CONNECTOR AKM1215
[ADR RESONANCE BLOCK]
SEMICONDUCTORS
IC1601-IC1603 TND304S
Q1604 2SA1163
Q1601 HAT1081R
Q1602,Q1603 HAT3019R
D1601 1SS302
D1608,D1609,D1617,D1618 EC10UA20
D1610,D1611,D1616,D1619,D1620 EC11FS2
D1604,D1612 MA126
D1602,D1606,D1607,D1614,D1615 UDZS15B
D1621,D1622 UDZS24B
COILS AND FILTERS
L1601,L1602 ATH1135
CAPACITORS
C1609,C1615 (0.47/100V) ACE1171
C1605,C1607,C1608,C1613,C1614 ACG1101
(0.01/100V)
C1601,C1602 (56/80V) ACH1347
C1618 (47/6.3V) ACH1357
C1603 (47/16V) ACH1391
C1604,C1606,C1612 CKSSYF104Z16
