Pioneer PDP-434PU - RS232 C Command Data Descriptions

PDP-434PU
51
5 678
56
7
8
C
D
F
A
B
E
Command description
Command Function
GAJ Obtaining various adjustment values
GPD Obtaining power-down-point log
GPW Obtaining panel white-balance adjustment values
GS1 Obtaining information on the unit, such as the software version
GS2 Obtaining information on the status of the unit
GSD Obtaining information on shutdown
GAJ: Obtaining data on ABL setting values, electronic-control adjustment values, and drive-system adjustment values
GPD: Obtaining power-down-point log on the panel
Note: Ignore the 2-byte checksum at the end.
Order Data Size Remarks
1 ABL table currently used 3 bytes AB1 - AB3
2 Upper limit of power 3 bytes 000 - 255
3 Vsus adjustment value 3 bytes 000 - 255
4 Vofs adjustment value 3 bytes 000 - 255
5 X-SUS-U1 adjustment value (XU1) 3 bytes 000 - 255
6 X-SUS-U2 adjustment value (XU2) 3 bytes 000 - 255
7 X-SUS-D2 adjustment value (XD2) 3 bytes 000 - 255
8 X-SUS-D1 adjustment value (XD1) 3 bytes 000 - 255
9 Y-SUS-U1 adjustment value (YU1) 3 bytes 000 - 255
10 Y-SUS-U2 adjustment value (YU2) 3 bytes 000 - 255
11 Y-SUS-D1-2 adjustment value (YD2) 3 bytes 000 - 255
12 Y-SUS-D1-1 adjustment value (YD1) 3 bytes 000 - 255
13 Y-SUS-D2-2 adjustment value (YD4) 3 bytes 000 - 255
14 Y-SUS-D2-1 adjustment value (YD3) 3 bytes 000 - 255
Order Data Size Remarks
1
Latest "1st PD" data
1 byte
0-C or F
2
Latest "2nd PD" data
1 byte
0-C or F
3
Data of hour meter for the latest PD
7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
4
Data on temperature for the latest PD (TEMP1)
3 bytes 000 - 255
5
Second latest "1st PD" data
1 byte
0-C or F
6
Second latest "2nd PD" data
1 byte
0-C or F
7 Data of hour meter for the second latest PD 7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
8 Data on temperature for the second latest PD (TEMP1) 3 bytes 000 - 255
9 Third latest "1st PD" data 1 byte
0-C or F
10 Third latest "2nd PD" data 1 byte
0-C or F
11 Data of hour meter for the third latest PD 7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
12 Data on temperature for the third latest PD (TEMP1) 3 bytes 000 - 255
13 Fourth latest "1st PD" data 1 byte
0-C or F
14 Fourth latest "2nd PD" data 1 byte
0-C or F
15 Data of hour meter for the fourth latest PD 7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
16 Data on temperature for the fourth latest PD (TEMP1) 3 bytes 000 - 255
17 Fifth latest "1st PD" data 1 byte
0-C or F
18 Fifth latest "2nd PD" data 1 byte
0-C or F
19 Data of hour meter for the fifth latest PD 7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
20 Data on temperature for the fifth latest PD (TEMP1) 3 bytes 000 - 255
21 Sixth latest "1st PD" data 1 byte
0-C or F
22 Sixth latest "2nd PD" data 1 byte
0-C or F
23 Data of hour meter for the sixth latest PD 7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
24 Data on temperature for the sixth latest PD (TEMP1) 3 bytes 000 - 255
25 Seventh latest "1st PD" data 1 byte
0-C or F
26 Seventh latest "2nd PD" data 1 byte
0-C or F
27 Data of hour meter for the seventh latest PD 7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
28 Data on temperature for the seventh latest PD (TEMP1) 3 bytes 000 - 255
29 Eighth latest "1st PD" data 1 byte
0-C or F
30 Eighth latest "2nd PD" data 1 byte
0-C or F
31 Data of hour meter for the eighth latest PD 7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
31 Data on temperature for the eighth latest PD (TEMP1) 3 bytes 000 - 255
Notes: • Ignore the 2-byte checksum at the end. • For details, see "Description on power-down."
