PDP-434PU
9
5 678
56
7
8
C
D
F
A
B
E
PACKING Parts List
(2) CONTRAST TABLE
PDP-434PU/ TUCK, PDP-434PE/ WYVI6, PDP-434PE/ WYVI6XK and PRO-434PU/ KUC are constructed the
same except for the following :
Mark
No. Description Part No.
>
1Power Cord See Contrast table (2)
>
2Power Cord See Contrast table (2)
3 Wiping Cloth AED1208
4 Binder Assy AEC1908
5 Code Case See Contrast table (2)
6 Center Pad (43) AHA2336
NSP 7 Warranty Card See Contrast table (2)
8 Mirror Mat See Contrast table (2)
9Pad (PP T- L) AHA2315
10 Pad (PP T- R) AHA2316
11 Pad (PP B- L) AHA2317
12 Pad (PP B- R) AHA2318
13 Carton (43) See Contrast table (2)
14 Upper Carton (43) See Contrast table (2)
15 Vinyl Bag AHG1310
16 Caution Card ARM1232
17 Speaker Cushion See Contrast table (2)
18 Vinyl Bag S See Contrast table (2)
19 Ferrite Core See Contrast table (2)
20 Inner Carton See Contrast table (2)
21 Polyethirene Sheet See Contrast table (2)
22 Paper See Contrast table (2)
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-434PU
TUCK
PDP-434PE
WYVI6
PDP-434PE
WYVI6XK
PRO-434PU
KUC
>
1Power Cord ADG1215 Not used Not used ADG1215
>
2Power Cord Not used ADG1214 ADG1214 Not used
5 Code Case AHC1041 AHC1041 AHC1049 Not used
NSP 7 Warranty Card ARY1138 ARY1114 ARY1114 ARY1134
8 Mirror Mat AHG1284 AHG1284 AHG1327 AHG1284
13 Carton (43PU) AHD3193 AHD3193 Not used Not used
13 Carton (43) Not used Not used AHD3189 Not used
13 Carton (43EL) Not used Not used Not used AHD3214
14 Upper Carton (43PU) AHD3179 Not used Not used Not used
14 Upper Carton (43PE) Not used AHD3180 Not used Not used
14 Upper Carton (43) Not used Not used AHD3188 Not used
14 Upper Carton (43EL) Not used Not used Not used AHD3215
17 Speaker Cushion AEB1384 AEB1384 AEB1384 Not used
18 Vinyl Bag S AHG1338 AHG1338 Not used AHG1338
19 Ferrite Core Not used ATX1039 ATX1039 Not used
20 Inner Carton Not used Not used Not used AHB1250
21 Polyethirene Sheet Not used Not used Not used AHG1341
22 Paper Not used Not used Not used AHG1342
To Next Page
