Pioneer XR-A4800 Service Manual

49
XR-A6800, XR-A4800
Mark No. Description Part No.
Mark No. Description Part No.
AF ASSY (XWZ3310)
SEMICONDUCTORS
IC3836 BA3838F
IC2101,IC3101,IC3102,IC3501,IC3502 BA4558F-HT
IC5691 BA4558F-HT
IC5751 BU1923F
IC5891,IC5892 BU4094BCF
IC2201 HA12136AF
IC2301 HA12211NT
IC3001 LC75394NED
IC42 NJM7805FA
IC32 NJM7812FA
IC3301 STK407-090B
Q3354,Q3601,Q3621,Q5751 2SA1037K
Q2806 2SB1197K
Q2803,Q2804 2SC1815
Q2801 2SC2240
Q2102,Q2201,Q2202,Q3101,Q3102 2SC2412K
Q3353,Q3603,Q3605-Q3608 2SC2412K
Q3081 2SD1858X
Q31 2SD2012
Q2203,Q2204,Q2805,Q3311,Q3312 2SD2114K
Q2301,Q2302,Q3501,Q3502 2SK368
Q3313,Q3503 DTA124EK
Q2104,Q2105,Q3314,Q5752 DTC124EK
Q2103,Q2306,Q2802,Q2807 DTC143EK
Q3352 IRF540A
Q3351 IRF9540A
D3301,D3302 1SR139-100
D2191,D2301-D2306,D3101,D3102 1SS133
D3351-D3354,D3361,D3362,D3601 1SS133
D3603,D3604,D3621,D3622 1SS133
D3625,D3626,D46 1SS133
D2102,D2103,D2201,D2202,D3051 1SS355
D63,D64 1SS355
D3355,D3356 20E2-FC
D3083 MTZJ11C
D61 MTZJ12C
D35,D36 MTZJ15C
D3359,D3360 MTZJ18B
D3363,D3364 MTZJ39C
D2001 MTZJ6.2A
D48 MTZJ6.8C
D3357,D3358 MTZJ7.5C
D51,D52 S5688G
COILS AND FILTERS
L3331-L3334 AF CHOKE COIL ATH-133
L2801 OSC COIL ATX7002
L2301,L2302 LTA822J
L101 FERRITE BEAD VTH1024
F2201,F2202 MPX FILTER XTF3002
L5751 AXIAL INDUCTOR XTL3002
RELAYS
RY3601 ASR7008
CAPACITORS
C3345,C3346 (0.01µF) ACG7021
C5756 CCSQCH561J50
C2301,C2302 CCSRCH100D50
C3001,C3002,C3047,C3048,C3858 CCSRCH101J50
C2192 CCSRCH220J50
C5751,C5752,C5755 CCSRCH270J50
C5757 CCSRCH271J50
C2327-C2330,C3321,C3322,C3852 CCSRCH470J50
C3854 CCSRCH470J50
C3994,C3995 CCSRCH681J50
C3319,C3320 CCSRCH6R0D50
C3311,C3312,C3507,C3508 CEANL1R0M50
C3317,C3318 CEANP220M35
C3621 CEANP2R2M2A
C3313,C3314 CEANP2R2M50
C3441 CEANP330M2A
C2207,C2803,C2810,C3045,C3115 CEAT100M50
C32,C33,C35,C3602,C3842 CEAT100M50
C43,C5691,C5692,C5758 CEAT100M50
C2002,C2316 CEAT101M16
C3303,C3304 CEAT101M50
C2312,C2313,C3035,C3036,C3110 CEAT1R0M50
C3506 CEAT1R0M50
C2106,C2214,C2215,C2321,C2322 CEAT220M50
C2001,C3601 CEAT221M16
C41 CEAT222M25
C2201,C2202,C2205,C2206 CEAT2R2M50
C2212,C2213,C2319,C2320 CEAT2R2M50
C3005-C3010,C3015-C3018,C3037 CEAT2R2M50
C3039,C3091,C3104 CEAT2R2M50
C2804,C2805,C5754 CEAT330M16
C3107 CEAT3R3M50
C3841 CEAT470M16
C3501,C3502,C3509,C3510 CEAT470M25
C3081,C3108,C3109,C3857 CEAT4R7M50
C3021,C3022 CEATR10M50
C2203,C2204 CEATR22M50
C3011,C3012,C3043,C3044,C3082 CEATR47M50
C3102,C3325 CEATR47M50
C3046 CEJA100M50
C3038,C3040 CEJA2R2M50
C3027,C3028 CFTLA334J50
C3023,C3024 CFTLA564J50
C2802 CKCYB681K2H
C2194 CKSQYB105K10
C3845 CKSQYB224K16
C3447,C3448,C3991,C5753,C5892 CKSRYB102K50
C1997,C2315,C2317,C2318,C3053 CKSRYB103K50
C3098,C3103,C3329,C3330 CKSRYB103K50
C2003,C2004,C2191,C2193 CKSRYB104K16
C3025,C3026,C3099,C3846,C3847 CKSRYB104K16
C5891 CKSRYB104K16
C3033,C3034,C3073-C3076 CKSRYB122K50
C2208,C2209 CKSRYB152K50
C3315,C3316 CKSRYB222K50
C2323,C2326 CKSRYB223K50
C2812,C2813 CKSRYB272K50
C2808,C2809 CKSRYB332K50
C2333,C2334 CKSRYB392K50
C2807,C3051,C3052,C3851,C3853 CKSRYB472K50
