Pioneer XR-A4800 Service Manual

50
XR-A6800, XR-A4800
Mark No. Description Part No.
Mark No. Description Part No.
C3855 CKSRYB472K50
C3101,C3111,C3112,C3844,C3850 CKSRYB473K16
C2303,C2304,C2343,C2344 CKSRYB561K50
C3029,C3030 CKSRYB563K16
C3019,C3020,C3031,C3032 CKSRYB682K50
C3503,C3504 CKSRYB682K50
C2307,C2308,C2331,C2332 CKSRYB821K50
C3331-C3333,C3335-C3338 CKSRYF104Z50
C2801 CQHA822J2A
C2210,C2211 CQMBA103J50
C2806 CQMBA223J50
RESISTORS
R2813 RD1/2LMF471J
R2809 RD1/2LMF4R7J
R2812 RD1/2LMF680J
R3333,R3334 RD1/4LMF101J
R3353,R3354 RD1/4PU101J
R3081 RD1/4PU221J
R3317,R3318 RD1/4PU823J
R3605 RS1/10S103J
R3357,R3358 RS1/10S153J
R2309 RS1/10S222J
R3330,R3611,R3612 RS1/10S223J
R2001 RS1/10S471J
R3319,R3320 RS1/10S561J
R3355,R3356 RS1/10S563J
R3315,R3316,R3603,R3604 RS1/10S823J
R61 RS1LMF821J
R3991,R3992 RS2LMF331J
R3601,R3602 RS3LMFR22J
VR2303-VR2306 (10kΩ) VCP1156
VR2301,VR2302 (100kΩ) VCP1162
VR2801,VR2802 (220kΩ) VCP1164
Other Resistors RS1/16S J
OTHERS
14P CABLE HOLDER 51063-1405
CN1052 8P FFC CONNECTOR 52045-0845
CN3331 4P SPEAKER TERMINAL AKE7018
X5751 CRYSTAL RESONATOR ASS7004
(4.332MHz)
CN2302 KR CONNECTOR B2B-PH-K-S
CN2303 KR CONNECTOR B3B-PH-K-R
CN2301 KR CONNECTOR B3B-PH-K-S
J11 JUMPER WIRE D15A14-450-2651
CN5105 27P FFC CONNECTOR HLEM27S-1
CN3051 14P PLUG KM200IB14
PCB BINDER VEF1040
JA3001,JA3441 2P PIN JACK VKB1060
JA3991 HEADPHONE JACK XKN3004
AF ASSY (XWZ3297)
SEMICONDUCTORS
IC3836 BA3838F
IC2101,IC3101,IC3102,IC3501,IC3502 BA4558F-HT
IC5691 BA4558F-HT
IC5751 BU1923F
IC5891 BU4094BCF
IC2301 HA12211NT
IC3001 LC75394NED
IC42 NJM7805FA
IC32 NJM7812FA
IC3301 STK407-070B
Q3354,Q3601,Q3621,Q5751 2SA1037K
Q2803,Q2804 2SC1815
Q3101,Q3102,Q3353,Q3603 2SC2412K
Q3605-Q3608 2SC2412K
Q3081 2SD1858X
Q31 2SD2012
Q2805,Q3311,Q3312 2SD2114K
Q2301,Q2302,Q3501,Q3502 2SK368
Q3313,Q3503 DTA124EK
Q3314,Q5752 DTC124EK
Q2306 DTC143EK
Q3351 IRFI9Z34G
Q3352 IRFIZ34G
D3301,D3302 1SR139-100
D2191 1SS133
D2301-D2306 1SS133
D3101,D3102 1SS133
D3351-D3354,D3361,D3362,D3601 1SS133
D3603,D3604,D3621,D3622 1SS133
D3625,D3626 1SS133
D46 1SS133
D2201,D2202,D3051,D63,D64 1SS355
D3355,D3356 20E2-FC
D3083 MTZJ11C
D61 MTZJ12C
D35,D36 MTZJ15C
D3359,D3360 MTZJ18B
D3363,D3364 MTZJ39C
D2001 MTZJ6.2A
D48 MTZJ6.8C
D3357,D3358 MTZJ7.5C
D51,D52 S5688G
COILS
L3331-L3334 AF CHOKE COIL ATH-133
L2801 OSC COIL ATX7002
L2301,L2302 LTA822J
L5751 AXIAL INDUCTOR XTL3002
RELAYS
RY3601 ASR7008
CAPACITORS
C3345,C3346 (0.01µF) ACG7021
C2335-C2338 CCCCH270J50
C5756 CCSQCH561J50
C2301,C2302 CCSRCH100D50
C3001,C3002,C3047,C3048,C3858 CCSRCH101J50
C2192 CCSRCH220J50
C5751,C5752,C5755 CCSRCH270J50
C5757 CCSRCH271J50
C2327-C2330,C3321,C3322,C3852 CCSRCH470J50
C3854 CCSRCH470J50
C3994,C3995 CCSRCH681J50
C3319,C3320 CCSRCH6R0D50
C3311,C3312,C3507,C3508 CEANL1R0M50
C3317,C3318 CEANP220M35
C3621 CEANP2R2M2A
