Pioneer XR-A4800 Service Manual

51
XR-A6800, XR-A4800
Mark No. Description Part No.
Mark No. Description Part No.
C3313,C3314 CEANP2R2M50
C2810,C3045,C3115,C32,C33 CEAT100M50
C35,C3602,C3842,C43 CEAT100M50
C5691,C5692,C5758 CEAT100M50
C2002,C2316 CEAT101M16
C3303,C3304 CEAT101M50
C2312,C2313,C3035,C3036,C3110 CEAT1R0M50
C3506 CEAT1R0M50
C2214,C2215,C2321,C2322 CEAT220M50
C2001,C3601 CEAT221M16
C41 CEAT222M25
C2212,C2213,C2319,C2320 CEAT2R2M50
C3005-C3010,C3015-C3018,C3037 CEAT2R2M50
C3039,C3091,C3104 CEAT2R2M50
C2804,C2805,C5754 CEAT330M16
C3107 CEAT3R3M50
C3841 CEAT470M16
C3501,C3502,C3509,C3510 CEAT470M25
C3081,C3108,C3109,C3857 CEAT4R7M50
C3021,C3022 CEATR10M50
C3011,C3012,C3043,C3044,C3082 CEATR47M50
C3102,C3325 CEATR47M50
C3046 CEJA100M50
C3038,C3040 CEJA2R2M50
C3027,C3028 CFTLA334J50
C3023,C3024 CFTLA564J50
C2194 CKSQYB105K10
C3845 CKSQYB224K16
C1997,C2315,C2317,C2318,C3053 CKSRYB103K50
C3098,C3103,C3329,C3330,C5753 CKSRYB103K50
C2191,C2193,C3025,C3026,C3099 CKSRYB104K16
C3846,C3847,C5891 CKSRYB104K16
C3033,C3034,C3073-C3076 CKSRYB122K50
C3315,C3316 CKSRYB222K50
C2323,C2326 CKSRYB223K50
C2812,C2813 CKSRYB272K50
C2808,C2809 CKSRYB332K50
C2333,C2334 CKSRYB392K50
C2807,C3051,C3052,C3853,C3855 CKSRYB472K50
C3101,C3111,C3112,C3844,C3850 CKSRYB473K16
C2303,C2304,C2343,C2344 CKSRYB561K50
C3029,C3030 CKSRYB563K16
C3019,C3020,C3031,C3032 CKSRYB682K50
C3503,C3504 CKSRYB682K50
C2307,C2308,C2331,C2332 CKSRYB821K50
C3331-C3333,C3335-C3338 CKSRYF104Z50
C2801 CQHA822J2A
C2806 CQMBA223J50
RESISTORS
R2812 RD1/2LMF470J
R2809 RD1/2LMF4R7J
R3333,R3334 RD1/4LMF101J
R3353,R3354 RD1/4PU101J
R2113 RD1/4PU103J
R3081 RD1/4PU221J
R3317,R3318 RD1/4PU823J
R3605 RS1/10S103J
R3357,R3358 RS1/10S153J
R2309 RS1/10S222J
R3330,R3611,R3612 RS1/10S223J
R2001 RS1/10S471J
R3319,R3320 RS1/10S561J
R3355,R3356 RS1/10S563J
R3315,R3316,R3603,R3604 RS1/10S823J
R61 RS1LMF821J
R3991,R3992 RS2LMF331J
R3601,R3602 RS3LMFR22J
VR2802 (100kΩ) VCP1162
Other Resistors RS1/16S J
OTHERS
14P CABLE HOLDER 51063-1405
CN1052 8P FFC CONNECTOR 52045-0845
CN5105 27P FFC CONNECTOR 52045-2745
CN3331 4P SPEAKER TERMINAL AKE7018
X5751 CRYSTAL RESONATOR ASS7004
(4.332MHz)
CN2302 KR CONNECTOR B2B-PH-K-S
CN2303 KR CONNECTOR B3B-PH-K-R
CN2301 KR CONNECTOR B3B-PH-K-S
J11 JUMPER WIRE D15A14-450-2651
CN3051 14P PLUG KM200IB14
PCB BINDER VEF1040
JA3001 2P PIN JACK VKB1060
JA3991 HEADPHONE JACK XKN3004
SECONDARY ASSY
SEMICONDUCTORS
IC71 (1.25A) AEK7010
IC41 (3A) AEK7015
IC12 (10A) AEK7022
IC21,IC22 (7A) AEK7047
IC11 (10A) AEK7068
Q71 2SA965
D73 1SS133
D11,D21 G5SBA20L
D74 MTZJ33C
D75 MTZJ8.2B
D71,D72,D78-D81 S5688G
CAPACITORS
C72 CEAT220M50
C71 CEAT221M63
C21,C22 CEAT332M50
C13 CQMA223K2E
C11,C12 (4700µF/71V) XCH3001
RESISTORS
All Resistors RD1/4PU J
OTHERS
14P CABLE HOLDER 51063-1405
PRIMARY ASSY
SEMICONDUCTORS
IC81 NJM7805FA
Q81 2SD1859X
D85,D88-D90 1SS133
D81 S1WB(A)60SD
