52
XR-A6800, XR-A4800
Mark No. Description Part No.
Mark No. Description Part No.
COIL
L1 LINE FILTER ATF1136
TRANSFORMERS
T2 XTT3004
RELAY
RY81 ASR7018
CAPACITORS
C1,C2 (0.01µF) ACE7027
C83 CEAT100M50
C82 CEAT102M25
RESISTORS
All Resistors RD1/4PU J
OTHERS
H1,H2 FUSE CLIP AKR7001
CN1 2P VH CONNECTOR B2P3-VH
CN2 4P VH CONNECTOR B4P7-VH
AN1 1P AC INLET XKP3041
DISPLAY ASSY
SEMICONDUCTORS
IC3901 BA4558F-HT
IC5501 PDC063A
Q5501 2SA1037K
Q2903,Q2906,Q2908 2SB1132
Q5602,Q5656-Q5658,Q5801 2SC2412K
Q2910,Q2911,Q5826 DTA124EK
Q5601 DTC124EK
Q2901,Q2904,Q2907,Q5502,Q5604 DTC143EK
Q5650-Q5655,Q5821-Q5825,Q5827 DTC143EK
D5593-D5596,D5626,D5811 1SS133
D5551-D5554,D5561-D5568 1SS181
D2901-D2903,D5631,D5652-D5655 1SS355
D5657,D5658,D5901 1SS355
D5601-D5608,D5610,D5611 SLP3118C51H
D5615,D5616,D5618,D5622,D5904 SLP3118C51H
D5612,D5614,D5617,D5621 SLP6118C51H
D5902 SLP7118C51H
D5619,D5620,D5903 SLP9118C51H
D5651 UDZS5.6B
COILS
L3901,L3902 CHIP COIL LCTB100K1608
L3914,L3915 CHIP SOLID INDUCTOR VTL1145
L5811 AXIAL INDUCTOR XTL3004
SWITCHES
S5911-S5921,S5923-S5929 XSG3001
S5931-S5940 XSG3001
S5951 XSX3003
S5952 XSX3004
CAPACITORS
C5812 (0.047F/5.5V) ACH1246
C3920,C3921 CCSRCH101J50
C3903 CCSRCH331J50
C3914,C3915 CCSRCH470J50
C3913 CCSRCH471J50
C5821 CEAL100M16
C5803 CEJA1R0M50
C3901,C3902,C3904,C3906 CEJA2R2M50
C3905,C5510,C5811,C5814 CEJA470M16
C5997,C5998 CKSQYB104K25
C5999 CKSQYB105K10
C5625 CKSQYF224Z25
C5804,C5951,C5953 CKSRYB102K50
C3911,C3951,C3952,C5995,C5996 CKSRYB103K50
C5816 CKSRYB104K16
C5506 CKSRYB471K50
C3907,C3909,C5503,C5504,C5509 CKSRYB472K50
C5507,C5508 CKSRYB473K16
C3922 CKSRYB561K50
C5634,C5901 CKSRYF104Z50
C5813,C5822 CKSRYF473Z50
RESISTORS
R5506,R5508 RA7T104J
R2905,R5524,R5536 RD1/4PU102J
R5601,R5613,R5617 RD1/4PU151J
R5530 RD1/4PU221J
R5609 RD1/4PU391J
R2902,R2907 RD1/4PU681J
R5805 RS1/10S101J
R5902-R5904 RS1/10S221J
R5614,R5616 RS1/10S471J
R5606-R5608 RS1/10S620J
VR3901 (10k-X1) XCS3002
Other Resistors RS1/16S J
OTHERS
X5501 CERAMIC RESONATOR DSS1048
(10MHz)
2P CABLE HOLDER 51048-0200
4P CABLE HOLDER 51048-0400
CN5502 FFC CONNECTOR 19P 52492-1920
JA3901,JA3902 AKN7004
REMOTE CONTROL JACK
J5601 JUMPER WIRE 2P D20PYY0210E
J81 JUMPER WIRE 4P D20PYY0425E
X5901 REMOTE RECEIVER UNIT GP1U28X
CN2901 FFC CONNECTOR 15P HLEM15R-1
CN5501 FFC CONNECTOR 27P HLEM27R-1
5621 FL HOLDER VNF1096
V5621 FL TUBE XAV3009
BLUE LED ASSY
SEMICONDUCTOR
D5613 E1L4E-7B(123)
OTHERS
2P CABLE HOLDER 51048-0200
LED HOLDER XAK3154
