Pipistrel ALPHA Trainer LSA User Manual

7-17
ALPHA Trainer LSA
Pilot Operating Handbook
POH-162-00-40-001
PAGE REV. 0
PAGE
SECTION 7
AIRPLANE DESCRIPTION
Kanardia Horis 0.23 A
Garmin GTR200 transceiver
0.51 A (Typical)
2.6 A (Max)
Garmin GTX335 transponder
0.72 A (Typical)
1.22 A (Max)
Landing light 5 A
NAV/AC lights
1 A (steady)
2 A (Peak)
Electrical trim 0.3 A
7.8.4 SWITCHES
MASTER BAT switch
The MASTER BAT toggle Switch activates the relay to connect the battery
with main bus. Main bus supplies the avionics relay which delivers the power
to the switch panel and circuit breakers. 12V socket is connected via switch/
fuse directly to the main battery. Starter button has no function when MAS-
TER BAT switch is OFF.
During normal operation the battery is always connected. It only disconnects
then the MASTER BAT switch is OFF.
MASTER GEN Switch
A toggle switch, labeled MASTER GEN, connects the generator to the bus.
7.8.5 WARNING LIGHTS
Generator Fail Light
The red GENERATOR FAIL Light on the upper-left side of the switch panel is
