7-18
PAGE
ALPHA Trainer LSA
Pilot Operating Handbook
POH-162-00-40-001
PAGE REV. 0
SECTION 7
AIRPLANE DESCRIPTION
connected to the voltage regulator. When ON, this means that the generator
is not operating. Normal state (generator operating) is when this LED light
is OFF.
NOTE: Engine RPM below 1600 will typically result in GENERATOR FAIL
warning light to come ON, however this is not a failure but a case of insu-
cient RPM to generate electrical power. Increase RPM.
Battery Caution Light
The orange Batt Caution light is installed on the switch panel only when
EarthX battery is installed. Batt Caution light is ON when the battery man-
agement system (BMS) integrated in the battery detects any malfunctions
(See Chapter 3 - Emergency procedures for additional details).
7.8.6 CIRCUIT BREAKERS AND FUSES
Individual electrical circuits connected to the Buses in the airplane are pro-
tected by re-settable circuit breakers mounted in the circuit breaker panel,
part of the main switch panel below the instrument panel.
7.8.7 MISCELLANEOUS COMPONENTS
Convenience Outlets
A 12-volt convenience outlet is installed on the switch panel. The receptacle
accepts a standard cigarette-lighter plug. The outlet may be used to pow-
er portable equipment non essential to flight. Amperage draw through the
outlet must not exceed 2 A. Power for the convenience outlet is supplied
through the 2-amp 12VDC OUTLET circuit breaker on the Battery Bus. USB
sockets are optionally available.
7.9 LIGHTNING
7.9.1 EXTERIOR LIGHTNING
Navigation Lights
The airplane can be equipped with LED standard wing tip navigation lights.
The lights are controlled through the NAV/AC light switch on the switch
