7-23
ALPHA Trainer LSA
Pilot Operating Handbook
POH-162-00-40-001
PAGE REV. 0
PAGE
SECTION 7
AIRPLANE DESCRIPTION
Center Console
The center console contains (front-to-back) throttle and choke lever, elevator
trim switch, brake lever and the flap lever.
7.13 FLIGHT INSTRUMENTS
The following paragraph lists a typical avionic configuration oered for the
aircraft. The avionics, navigation and communication equipment are mount-
ed in the instrument panel and are easily accessible from either pilot seat.
NOTE: Please refer to OEM documentation for additional information about
individual equipment, or for optional equipment not mentioned in the config-
uration described below.
The typical avionics configuration consists of:
1 Airspeed Indicator Kanardia
2 Altimeter Kanardia
3 Variometer Kanardia
4 Tachometer (RPM) Kanardia
5
Engine Management System Kanardia
(Engine Data Acquisition unit Daqu and display DiGi)
6 Radio COM Garmin GTR 200
7 Transponder Garmin GTX 335
8
GPS Garmin Aera 660
9 Airbrakes control panel
10 Mechanical Compass
11 Slipball Winter
12 ELT Artex 345 (option)
13 Kanardia Horis display
14 Electric Trim
15 Switches and breakers
