2-5
ALPHA Trainer LSA
Pilot Operating Handbook
POH-162-00-40-001
PAGE REV. 0
PAGE
SECTION 2
LIMITATIONS
Minimum Oil Temperature 50 °C (120 °F)
Normal Oil Temperature 90 °C - 110 °C (190 - 230 °F)
Maximum Oil Temperature 140°C (285 °F)
Minimum Coolant Temperature not limited
Maximum Coolant Temperature 120 °C (248 °F)
Maximum Exhaust Gas Tempera-
ture
880 °C (1616 °F)
2.5 ENGINE INSTRUMENT MARKINGS
INSTRUMENT
RANGE
RED LINE GREEN ARC YELLOW ARC RED LINE
MINIMUM NORMAL CAUTION MAXIMUM
Tachometer
(0 - 7000 RPM)
1400 1400 - 5500 5500 - 5800 5800
Coolant Temp.
(/ - 120 °C)
(/ - 248 °F)
–– –– ––
120 °C
(248 °F)
Exhaust Gas Temp.
(650 - 925 °C)
(1202 - 1697 °F)
650 °C
(1202 °F)
750 - 850 °C
(1382-1562 °F)
850 - 925 °C
(1562-1697 °F)
925 °C
(1697 °F)
Manifold Pressure
(0 - 35 inHg)
–– 15 - 29.5 inHg –– ––
Fuel Pressure
(0 - 0.4 bar)
(0 - 0.4 psi)
0.01 bar
(0.21 psi)
0.01 - 0.4 bar
(0.21 - 5.8 psi)
––
0.4 bar
(5.8 psi)
Oil Temperature
(0 - 140 °C)
(0 - 285 °F)
50 °C
(120 °F)
90 - 110 °C
(190 - 230 °F)
110 - 125 °C
(230 - 257 °F)
140 °C
(285 °F)
Oil Pressure
(0 - 7 bar)
(0 - 101 psi)
1 bar
(14.5 psi)
1.5 - 5 bar
(21.7 - 72.5 psi)
5 - 6.5 bar
(72.5 - 94.2 psi)
6.5 bar
(94.2 psi)
Voltmeter
(10 - 16 V)
11.4 V 11.4–14.4 V –– 14.4 V
