ENGLISH
8
• Mount the bottom shelf to each leg with wheel using a screw, locking
washer, and washer. Ensure the flat surface of the shelf is facing up
towards the grill barrel. Note 2B.
132
23
131
2
2
2
• Mount one stationary leg to the hopper end of the main barrel
using three screws, locking washers, and washers, through the three
predrilled holes. Install screws from the inside of the main barrel.
Repeat installation for second stationary support leg. Note 2C.
• Connect the bottom shelf to both stationary legs with the final
two screws, locking washers, and washers. Once the shelf is secure,
carefully lift the grill into an upright position. Note 2D.
23
3.
Parts Required:
1 x Lid Stopper (#5)
Installation:
• Secure the lid stopper onto the top of the main barrel using the pre-
installed screw on the top of the main barrel.
5
3
