MODEL SG6H FRYER TROUBLESHOOTING
L20-332, rev. 1 (05/11) 25
4.4. SELF CLEANING BURNER SYSTEM (NOT ON ALL MODELS)
If your appliance is equipped with the self cleaning burner system, the appliance should behave as
outlined in the table below. A cleaning cycle will execute every time the appliance is turned “ON” from
an “OFF” state. The thermal cut out switch is designed to disable the appliance if the Self Cleaning
Burner System malfunctions and remains activated for an extended period of time or if there is a
downdraft into the flue or a blocked flue situation.
Event Duration Indication
Turn appliance “ON” N/A
Control Illuminates, pilot sparks and ignites. Pre-Purge
pulse is initiated.
Pre-Purge Pulse 2 seconds Appliance operates briefly and stops. Pilot remains lit.
Interwaiting period 1 5 seconds Appliance does not operate. Pilot remains lit.
Cleaning Pulse 6 seconds
Main valve operates, lighting main burners. SCBS valve
operates, feeding gas to the SCBS Arm. The SCBS arm
ignites, initiating a brief burn at the main burner orifice of
each burner.
Interwaiting period 2 8 seconds
The Main and SCBS valves de-energize for this period.
The pilot remains lit.
Normal operation
resumes
N/A
The appliance operates normally and begins to heat up.
The SCBS Valve remains de-energized until power to
the appliance is recycled. There is no flame on the
SCBS Arm. There is no burn at the main burner orifices.
