Connecting the
CUBE V AC
single-phase
Simply introduce the cable
with the Schuko plug into
the hole at the bottom of
CUBE and connect the plug
to a grounded outlet of the
household type.
Connect the ground wire
to a grounding connection
prepared according to
regulations.
Connecting
CUBE DC
Connect the power cord following the
polarity and lock it as shown in the
drawing.
CUBE dispensers are not equipped with
circuit breakers. It is therefore strongly
recommended to install on the plug a
-mA residual current operated circuit
breaker.
ATTENTION
The direction of the
selector should be as
shown in the picture.
Fuses:
¦ V version =A
¦ V version =A
Cables:
¦ for CUBE DC V use
twin core cable with
minimum conductor
cross section of mm
2
.
¦ for CUBE DC V use
twin core cable with
minimum conductor
cross section of 6 mm
2
.
NOTE
blue
brown
STARTINGO.
Filling the pump
The pump provided with CUBE is a self-priming pump capable of
suctioning an empty hose, nevertheless, the pump should be partially
filled with diesel fuel before turning it on for the first time.
It is le to the technician's experience to determine the best way to fill
the pump.
