Pixsys ATR 121 Series User Manual

User manual - ATR121 - 41
Table of configuration parameters
01
c.ou
Command output 27
02
sen
Sensor 28
03
d . p.
Decimal point 28
04
Lo . s
Lower Limit Setpoint 28
05
Hi . s .
Upper Limit Setpoint 29
06
Lo. N
Lower Linear Input 29
07
Hi . n
Upper Linear Input 29
08
La t
Latch On function 29
09
cA. o
Offset calibration 29
10
cA.G
Gain calibration 30
11
ReG.
Regulation type 30
12
S. c. c.
Command state error 30
13
Ld1
Command led 30
14
HY. c
Command hysteresis 30
15
p. b.
Proportional band 31
16
t.i .
Integral time 31
17
t.d .
Derivative time 31
18
t. c.
Cycle time 31
19
AL.
Alarm 31
20
c.r.a
Alarm state output 32
21
s.c.a
Alarm state error 32
22
Ld2
Alarm led 32
23
HY. a
Alarm Hysteresis 32
24
de. a
Alarm delay 32
25
p.se.
Setpoint protection 32
26
fi L
Conversion filter 33
27
tun
Tune 33
28
fnc
Operating / visualization mode 33
