ATR 421 - User manual 53
31
s.spu
Cycle start setpoint
32
sp.fu.
Special functions
33
HLd . f.
Hold function
34
cY.A u .
Number of cycles availables for the user
35
b.pr.c.
Number of cycles which cannot be programmed
by the user
36
w.t.s.e.
End step waiting time
37
m.G.s.e.
Max. gap for end step waiting
38
r.i . cY.
Interrupted cycle recovery
39
bu.st.
Time for burners starting
40
t.s.o.b.
Threshold for burners switch-of
41
b. HY.
Hysteresis for burners command
42
t.s.o . f.
Threshold for fans switch-of
43
uaL.t.
Time for servo-valve opening/closure
44
fe.po.
Feedback potentiometer for motorized valves
45
AL. 1
Alarm 1 selection
46
a.1.s.o.
Alarm 1 output contact type
47
a.1.tH.
Alarm 1 setpoint value
48
a.1.HY.
Alarm 1 hysteresis
49
a.1.s.e.
Alarm 1 output contact status in case of error
50
a.1.Ld.
Led A1 ON status
51
a.1.a.t.
Alarm 1 action type on operating cycle
52
aL. 2
Alarm 2 selection
53
a.2.s.o.
Alarm 2output contact type
54
a.2.tH.
Alarm 2 setpoint value
55
a.2.HY.
Alarm 2 hysteresis
56
a.2.s.e.
Alarm 2 output contact status in case of error
57
a.2.Ld.
Led A2 ON status
58
a.2.a.t.
Alarm 2 action type on operating cycle
59
aL. 3
Alarm 3 selection
60
a.3.s.o
Alarm 3 output contact type
61
a.3.tH.
Alarm 3 setpoint value
62
a.3.HY.
Alarm 3 hysteresis
63
a.3.s.e.
Alarm 3 output contact status in case of error
64
a.3.Ld.
Led A3 ON status
65
a.3.a.t.
Alarm 3 action type on operating cycle
66
aL. 4
Alarm 4 selection
67
a.4.s.o.
Alarm 4 output contact type
