User manual - ATR224 - DRR224 - 25
GROUP G -
AL.1
- Alarm 1
123
AL.1. f.
Alarm 1 Function
Alarm  selection.
diS a b.
Disabled (Default)
A b . u p. A .
Absolute Upper Activation. Absolute referred to the process, active over
Ab.Lo.a.
Absolute Lower Activation. Absolute referred to the process, active under
bAnd
Band alarm (command setpoint ± alarm setpoint)
u p. d e v.
Upper Deviation alarm
L o . d e v.
Lower Deviation alarm
126
A.I.5. o .
Alarm 1 State Output
Alarm  output contact and intervention type.
n.o. S t.
(N.O. Start) №rmally open, active at start (Default)
n.c. St.
(N.C. Start) №rmally closed, active at start
n.o. tH.
(N.O. Threshold) №rmally open, active on reaching alarm
2 p. 33
n.c. tH.
(N.C. Threshold) №rmally closed, active on reaching alarm
2 p. 33
n.o.tH.V.
(N.O. Threshold Variation) disabled after changing control setpoint
3 p. 33
n.c.tH.V.
(N.C. Threshold Variation) disabled after changing control setpoint
3 p. 33
127
rEs .
Reserved
Reserved parameter.
128
a .1.Hy.
Alarm 1 Hysteresis
Alarm  hysteresis
-..+ [digit
 p. 
] (degrees for temp. sensors). Default ..
129
A.1.L.L.
Alarm 1 Lower Limit
Lower limit selectable for the alarm  setpoint.
-..+ [digit
 p. 
] (degrees for temp. sensors). Default .
130
A.1. u .L.
Alarm 1 Upper Limit
Upper limit selectable for the alarm  setpoint
-..+ [digit
 p. 
] (degrees for temp. sensors). Default.
131
a .1. re.
Alarm 1 Reset
Alarm  contact reset type (always automatic if
A L.1. F.
=
c. A ux
).
A. r Es.
Automatic reset (Default)
M. r Es.
Manual reset (manual reset by keyboard or by digital input)
M.r Es.S.
Stored manual reset (keeps the output status also after a power failure)
A. r Es.t.
Automatic reset with timed activation. The alarm remains active for the time set on the
parameter 134
a.1. d e.
, even if the conditions generating it are missing. To be able to act
again, the alarm conditions must disappear.
132
A.1.S. e.
Alarm 1 State Error
Alarm  output status in case of error.
open
Open contact. Default
CLose
Closed contact.
133
A.1.Ld .
Alarm 1 Led
Defines the status of the led A in correspondence of the relevant output
o.c.
ON with open contact or DO switched off.
c.c.
ON with closed contact or DO switched on. (Default)
