Setting Analyzer switch-on behavior. The analyzer starts with the
selection menu, or with the mode at the last power off.
Possible values: dBuV, dBmV, dBm.
Selecting channel allocation standard.
4.6 Analyzer Self-Test
To check the correct functioning of the analyzer individual components and the operating
conditions, the device self-test mode is intended. The icon in the main selection menu
corresponds to the mode. The self-test screen view is shown in Figure 4.19:
The table contains the following verifiable parameters:
Remaining capacity of the Data Logger memory.
Temperature inside the analyzer.
State of calibration coefficients tables (faultless or failed).
Faultless operation of analyzer internal parts.
Each parameter is followed by a status at the end of the row. If the icon color is green, then the
parameter is normal. If red, it means a problem is detected.
If there is not enough free memory, which is indicated by the error indicator, then unnecessary
files should be deleted from the memory of the Data Logger. If the error does not disappear, then
contact the service center.
