24
4.4.4.5 Scanning Channel Data Logger Page
To start scanning the selected Channel Data Logger page (Section Ошибка! Источник ссылки не
найден.), press the «F2/Start». A table for preparing scan data (Figure 4.12) will appear on the
screen where you can tune the measurement parameters and scan speed. Press «F1/Ok» to
confirm the start. The scan progress table will appear on the screen. After the scan is complete,
you can save the results and go to the data view mode.
4.4.4.6 Deleting Channel Data Logger Page
To delete the selected Channel Data Logger page, press «F1/Page» and select Delete. A
confirmation dialog will appear on the screen. You can cancel or confirm page deletion.
4.5 General Settings
The General Settings mode is designed to set the modes of the analyzer's overall operation. To
start the mode in the main selection menu, select the icon set and using « » and « » set
the icon in the bottom row of the screen. Use «F1/Config» to start the mode (Figure 4.18).
Figure 4.18
The table contains 7 parameters for selecting the operating mode:
Selecting a Graphical user interface language.
Selecting a color set of the graphical interface.
Key sound indication control.
Setting Analyzer automatic switch-off. Power off after the last button
press.
Setting automatic backlight switch-off mode.
