Step 4. Connecting 802.3af/802.3at PoE Device
802.3af/at PoE Device
PoE
PoE
PoE
PoE
1. Connect the PoE devices to ports 1~4 on the BSP-360.
2. Check the PoE-in-Use LED. If the network devices such as PoE camera and PoE
wireless AP are powered, the PoE-in-use LED will turn ON and Link/Act LED
will blink for a successful connection or data receiving.
Note
Please use Cat5/5e or above cable and the maximum distance
should within 100 meters.
If the Network devices are installed outdoors, please consider
to install a well-grounded lightning arrestor (such as PLANET
ELA-100) to protect the network device and the BSP-360.
