7
Hardware
z 9-inch desktop size, 1U height, rack mountable
z LED indicators for system power, per port PoE ready and PoE activity, speed,
Link/Act
z Fanless design
z Supports Energy-Efcient Ethernet (EEE) function (IEEE 802.3az)
1.4 Specications
Model FSD-1008HP
Hardware Specications
Copper Port 10 10/100/BASE-TX MDI/MDIX Ports
PoE Injector Port
8-port with 802.3at/af PoE injector function with
Port-1 to Port-8
Switch Architecture Store-and-Forward
Switch Fabric 2Gbps/non-blocking
Switch Throughput@64 bytes 1.48Mpps@64 bytes
MAC Address Table
8K entries, automatic source address learning
and aging
Maximum Frame Size 1522 bytes
Flow Control
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
LED
System:
Power (Green)
10/100BASE-TX RJ45 interfaces:
10/100Mbps LNK/ACT (Green)
PoE interfaces:
PoE-in-Use (Orange)
DIP Switch
Selectable operation mode
Standard
VLAN
Extend
Dimensions (W x D x H) 220 x 150 x 43 mm (1U height)
Enclosure Metal
