Cable Connection Parameter
The cable distance limitations are as below:
Duplex Connection Limitation (max.)
Twisted Pair
Half / Full
Node to Node
Node to Switch/Hub
100 meters
Multi-Mode Converters
MM Half*
Node to Node
Node to Switch
412 meters
MM Full
Node to Node
Node to Switch
2 kilometers
Single-Mode Converters (FT-70xS, FT-706A15/706B15)
SM Full
Node to Node
Node to Switch
FT-70xS15: 15 km
FT-70xS35: 35 km
FT-70xS50: 50 km
FT-706A15: 15 km
FT-706B15: 15 km
NOTE:
If the ber port works on half duplex, please
note that Fast Ethernet/100Base-TX network
allows 512 bit-time delay between any two
nodes/stations in a collision domain (when work
in half duplex). The overall bit time of TP/Fiber
wires and devices must below 512 bit-time in
one network segment. To extend the distance,
however, you may use switch to break up a
collision domain and extend the distance.
