1
Chapter 1
Overview
Thank you for purchasing PLANET FT-70X family Fast Ethernet
Twisted pair to Fiber-optic Converter. This converter is used to
convert one type media signal to other type equivalent that allows
two type segments connect easily, efciently and inexpensively.
This converter can be used as a standalone unit or as a slide-in
module to the 10 /19 media chassis (up to 15 units) for a TP
and Fiber combined networks at a central wiring closet. Please
contact with your sales representative for more about the 19
media chassis.
Chapter 2
Model List
Your Fast Ethernet Converter comes with one of the following
models.
ð FT-701B on board ST fiber connector
ð FT-702B/S on board SC fiber connector
ð FT-703/S on board MT-RJ fiber connector
ð FT-704/S on board VF-45 fiber connector
ð FT-706A15 on board single SC fiber connector
ð FT-706B15 on board single SC fiber connector
Models with last two numbered characters indicates the ber-
port is with Single-Mode optic ber connector and the number
indicates the maximum distance in km. The rest will be Multi-
Mode optic ber models.
In the following sections, the term FT-70X indicates the product
family above.
