Planet GS-4210-24P2S User Manual

10
7. Starting Web Management
The following shows how to start up the Web Management of the PoE Managed
Switch. Note the PoE Managed Switch is congured through an Ethernet
connection. Please make sure the manager PC must be set on the same IP
subnet address.
Forexample,thedefaultIPaddressofthePoEManagedSwitchis192.168.0.100;
then the manager PC should be set at 192.168.0.x (where x is a number
between1and254,except100)andthedefaultsubnetmaskis255.255.255.0.
PC / Workstation
with Web Browser
192.168.0.x
Managed Switch
RJ-45/UTP Cable
IP Address:
192.168.0.100
Figure 7-1: IP Management Diagram
 Logging in the PoE Managed Switch
1.Use Internet Explorer 8.0 or above Web browser and enter IP address
http://192.168.0.100 toaccesstheWebinterface.
