3. Terminal Setup
Tocongure the system,connectaserial cabletoaCOM portonaPC or notebook
computerandtoRJ-45typeofconsoleportofthePoEManagedSwitch.
PoE Managed Switch
PC / Workstation
with
Terminal emulation software
Serial Port
Serial Port
115200,8,n,1
RS-232 to RJ-45 Cable
Figure 3-1: PoE Managed Switch Console Connectivity
A terminal program is required to make the software connection to the PoE
ManagedSwitch.
1. Run terminal program on the OS.
2.When the following screen appears, make sure that the COM port should be
conguredas:
z Baud :115200
z Databits :8
z Parity :None
z Stopbits :1
z Flowcontrol :None
Figure 3-2: COM Port Conguration
