8
duplex for 10Mbps and 100Mbps, full-duplex for 1000Mbps
Supports maximum frame size up to 1522 bytes l
IEEE 802.1Q Tag VLAN Transparent, Multicast pass through l
Redundancy
Link status auto-detect and redundant on Dual ports with l
same connector type
Only Primary-Port is active at a time, the Backup-Port is l
blocked
While Primary-Port link fail occurrences, the trafc swaps to l
Backup-Port automatically
Once the Primary-Port status backs to link up, the trafc l
swaps from Backup-Port to Primary-Port
Hardware ber port redundant l
Mechanical
External 5V / 2A DC power supply l
LED indicators for easy network diagnose l
DIP Switch for 3-Port operation with Gigabit Switch mode or l
Redundant mode
Compact in size, easy installation l
Can be installed on PLANET’s 10”/19” Media Converter Chassis l
(MC-700/1500/1500R/1500R48)
Wall mounting and DIN-Rail Supported l
