3.1 Grounding the Device
Users MUST complete grounding wired with the device; otherwise, a sudden
lightning could cause fatal damage to the device.
V1+ V2+
PWR1
PWR2Fault
DC Input: 12-48V
, 1.2A max.
AC Input: 24V
, 1.1A max.
Max. fault loading: 24V, 1A
1 2 3 4 5 6
Earth Ground
