Planet ISW-808PT-M12 User Manual

9
2.4 M12 (4-pin, Male) to RJ45 (8-pin) Cable
1
8
1
4
2
3
M12-4P(M)-D
Note
As each Ethernet port of the Industrial M12 Ethernet Switch is
running in auto negotiation mode, make sure the Ethernet ports
of the corresponding Ethernet devices are also running in auto
negotiation mode, otherwise, the Ethernet performance will be
poor.
TX+
RX+
TX
-
RX -
1
2
3
4
1
2
3
6
TX+
TX
-
RX+
RX
-
M12(4-Pin, M) to RJ-45(8-Pin) Cross-Over Cable Wiring
Cross-Over Cable Wiring
TX+
RX+
TX
-
RX -
1
2
3
4
1
2
3
6
RX+
RX
-
TX+
TX
-
M12(4-Pin, M) to RJ-45(8-Pin) Straight-Trough Cable Wiring
Straight-through Cable Wiring
