Planet LRP-101C-KIT User Manual

14
Long
Reach
PoE
Interface
Connectivity
1 x RJ45 connector
Long Reach PoE over
UTP PSE
(Power Source
Equipment)
1 x RJ45 connector
Long Reach PoE over
UTP PD (Powered
Device)
Power Input ─ 37~56V DC
Power Output 41~56V DC
Power Pin
assignment
RJ45 PIN 1,3,5,7: VCC+ RJ45 PIN 1,3,5,7: VCC+
RJ45 PIN 2,4,6,8: VCC- RJ45 PIN 2,4,6,8: VCC-
Cabling UTP cable:
Maximum
distance
Max. 100m with PoE+ output (328 ft.)
Max. 400m with PoE output (1,312 ft.)
Max. 500m without PoE output (1,640 ft.)
Long Reach
Ethernet
Standard
IEEE 1901
Modulation Type Wavelet-OFDM
Security 128-bit AES encryption
Frequency Band 2 ~ 28 MHz
Encryption AES 128-bit
Performance**
Distance
Data Rate*
(Upload /
Download)
LRP-101UE 802.3af/at
PoE Output Capability**
LRP-101UH
W/56V DC
IN
LRP-101UH
W/30W
PoE+ IN
100m 94 / 94 Mbps 30W 19W
200m 82 / 82 Mbps 30W 18W
300m 63 / 67 Mbps 30W 17W
400m 44 / 48 Mbps 22W 14W
500m 30 / 30 Mbps 18W 12W
