Planet LRP-101C-KIT - Page 15

15
LED Indicators
4 x LEDs
 PWR
 LRP LNK
 PoE IN
 LNK/ACT
4 x LEDs
 PWR
 LRP LNK
 PoE-in-use
 LNK/ACT
ESD Protection 2KV DC
EFT Protection 2KV ─
Enclosure Metal case
Installation Wall mount or DIN rail with optional kit
Dimensions (W x D x H) 94 x 70 x 26 mm
Weight 193g 190g
Power Requirements
 RJ45 PoE Input:
802.3at/af 48~56V
DC
 DC Input: 48~56V DC
Power over RJ45 Input:
44~56V DC
Standards Conformance
Standards Compliance
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3af Power over Ethernet (802.3at Type 1)
IEEE 802.3at Power over Ethernet (802.3at Type 2)
Regulation Compliance FCC Part 15 Class A, CE
Environment
Temperature
Operating: -20~70 degrees C
Storage: -40~75 degrees C
Humidity
Operating: 5~95% (non-condensing)
Storage: 5~95% (non-condensing)
* 1. Upload: LRP-101UE to LRP-101UH. Download: LRP-101UH to LRP-
101UE.
2. As there are various resistance values in the category 5/5e cable,
the actual data rate will vary on the quality of the copper wire and
environment factors.
** Depending on what the DC/PoE Power Input and the length of UTP
cable are.
