8. Starting Web Management
The following shows how to start up the Web Management of the LRP Managed
Switch. Note the LRP Managed Switch is congured through an Ethernet
connection. Please make sure the manager PC must be set on the same IP
subnet address.
Forexample,thedefaultIPaddressoftheLRPManagedSwitchis192.168.0.100,
then the manager PC should be set at 192.168.0.x (where x is a number
between1and254,except100),andthedefaultsubnetmaskis255.255.255.0.
PC / Workstation
with Web Browser
192.168.0.x
Managed Switch
RJ45/UTP Cable
IP Address:
192.168.0.100
Figure 8-1: IP Management Diagram
