9. Starting Long Reach PoE Communication
Thefollowingshows howtostartup theLong Reach PoE Communication ofthe
LRPManagedSwitchfromWebManagement.
Note
TheLRPManagedSwitchisconfigured DISABLED Long Reach PoE
functionasdefault.
 Connect the Coaxial Cable
1.Insert thecoaxial cablewith oneside beingthe 75ΩBNCplug connectorinto the
LongReachEthernetcoaxialinterface.
2.Connect the other end of the cable to a device with Long Reach Ethernet
coaxial extenderinstalled.
3.TightentheBNCmaleconnectorgently.
5C2V/RG6 75Ω Coaxial Cable
RJ45
PoE PT Camera
Long Reach Power over Ethernet
2
1
LRP-422CST
LRP-101CE
