User Manual of WDAP-C3000AX, WDAP-3000AX, WDAP-W3000AX
- 30 -
Step 2. Load the device into the mounting bracket, and be sure the device is mated with
fixed screws. Then, lock the device in position and plug the Ethernet cable into the
WDAP-C3000AX.
Figure 3-2 Connecting the Ethernet Cable
Step 3. Plug the other end of the Ethernet cable into the PoE switch.
Figure 3-3 Connecting the PoE Injector
