DIP Switch
Multi-operation mode options
(Standard/VLAN/Extend) selection
Power Consumption
8.6 watts/29 BTU (Power On)
82 watts/279 BTU (Full loading with PoE function)
Power over Ethernet
PoE Standard
PoE in Port
- IEEE 802.3bt PoE++ Type 4 standard PD
- IEEE 802.3at PoE+ end-span/mid-span PD
Per PoE out Port
- IEEE 802.3at Power over Ethernet Plus end-span
PSE
PoE Power
PoE in Port
50~57V DC, max. 95 watts
Per PoE out Port
44~55V DC, max. 30.8 watts
Power Pin Assignment
PoE in Port
1/2(-), 3/6(+), 4/5(+), 7/8(-) or 1/2(+), 3/6(-),
4/5(+), 7/8(-)
Per PoE out Port
1/2(+), 3/6(-)
PoE Power Budget 65-70 watts (max.) @ 802.3bt PoE++ Type 4 input
Standards Conformance
Regulatory Compliance FCC Part 15 Class A, CE
Stability Testing
IEC60068-2-32 free fall
IEC60068-2-27 shock
IEC60068-2-6 vibration
Standards Compliance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3x Flow Control
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
IEEE 802.3bt Power over Ethernet Plus Plus
