5.TechnicalSpecications
Model WGS-E304PT
HardwareSpecications
Network Connector
PoE In Port
- 1 x 10/100/1000BASE-T Ethernet with 802.3bt
PoE++ “Data + DC” in
- Auto MDI/MDI-X, auto-negotiation RJ45 connector
PoE Out Port
- 4 x 10/100/1000BASE-T Ethernet with IEEE
802.3af/at PoE “Data + DC” out
- Auto MDI/MDI-X, auto-negotiation RJ45 connector
Switch Architecture Store-and-Forward switch architecture
MAC Address Table 2K MAC address table with auto learning function
Switch Fabric 10Gbps
Switch Throughput 7.44Mpps @ 64Bytes
Flow Control
IEEE 802.3x pause frame for full duplex
Back pressure for half duplex
Jumbo Frame 9Kbytes
ESD Protection
Air 8KV DC
Contact 6KV DC
Surge Protection 6KV
Enclosure IP30 metal case
Installation DIN-rail kit and wall-mount ear
Dimensions
(W x D x H)
148 x 24.2 x 134 mm
Weignt 457g
LED
PoE Input Port (Port 5):
LNK/ACT(Green)
PoE: Power-in-use (Amber)
PoE Output Ports (Ports 1~4):
LNK/ACT(Green)
PoE: Power-in-use (Amber)
