4. Power over Ethernet Budget
The following table lists how many PoE devices can be powered by the
Industrial PoE Extender under 1m in distance:
Power Source PoE Output Budget Max. Number of PDs supported
95W 802.3bt
PoE++
Type 4 PSE
65 watts max.
Class 4 PD@25 watts 2 units
Class 3 PD@12.9 watts 4 units
Class 2 PD@7 watts 4 units
60W 802.3bt
PoE++
Type 3 PSE
60 watts max.
Class 4 PD@25 watts 2 units
Class 3 PD@12.9 watts 4 units
Class 2 PD@7 watts 4 units
36W 802.3at
PoE+ PSE
36 watts max.
Class 3 PD@12.9 watts 2 units
Class 2 PD@7 watts 4 units
Remarks:
1.The PoE output budget means the aggregated power output of the 4 PSE
ports.
2. The aggregated power consumption will be below 70 watts if with PoE+
PSE.
3. Please check the power input LED for optimal power output.
