WAN Port 1 x 10/100Base-TX, Auto-MDI/MDI-X
LAN Port 4 x 10/100Base-TX, Auto-MDI/MDI-X
Antenna Dipole Antenna * 1
Data Encryption 64 bit / 128 bit WEP, WPA-PSK, WPA, WPA2
Frequency 2.4GHz - 2.484GHz
Sensitivity
11g @ PER < 10%
54Mbps: -71.46 dBm
48Mbps: -73.1 dBm
36Mbps: -75 dBm
24Mbps: -77 dBm
18Mbps: -79.1 dBm
12Mbps: -81.1 dBm
9Mbps: -83.5 dBm
6Mbps: -85.52 dBm
11b @ PER < 8%
11Mbps: -82 dBm
5.5Mbps: -85.7dBm
2Mbps: -87 dBm
1Mbps: -91.5 dBm
Data Rate Up to 54Mbps (with automatic scale back)
LED Indicators PWR, WLAN
LAN: LNK/ACT * 4, 10/100Mbps * 4
WAN: LNK/ACT * 1, 10/100Mbps * 1
Power Requirement 12V DC, 1A
Power Consumption TX power consumption: <650mA
RX power consumption <350mA
Temperature Operating :0 ~ 55 degree C
Storage: -20 ~ 70 degree C
Humidity Operating: 0 ~ 90%
Storage: 0 ~ 95% Non-Condensing
Dimensions 190 x 98 x 35 mm
Output Power 18dBm
