Planmeca ProMax 3D Plus User Manual

Planmeca ProMax 3D Plus & 3D Mid with ProTouch 17
PLANMECA PROMAX 3D PLUS PROGRAMS
User’s Manual (3D)
7 PLANMECA PROMAX 3D PLUS PROGRAMS
7.1 3D Dental
7.1.1 Volume sizes for children
7.1.2 Volume sizes for adults
7.2 3D Ear Nose Throat
7.2.1 Volume sizes for children
Program Ø34 mm Ø60 mm Ø75 mm Ø140 mm
TOOTH Ø34 x H42 mm
Ø34 x H60 mm
TEETH Ø60 x H42 mm
Ø60 x H60 mm
Ø75 x H42 mm
Ø75 x H75 mm
JAW Ø140 x H50 mm
Ø140 x H90 mm
Program Ø40 mm Ø70 mm Ø90 mm Ø140 mm
TOOTH Ø40 x H50 mm
Ø40 x H70 mm
TEETH Ø70 x H50 mm
Ø70 x H70 mm
Ø90 x H50 mm
Ø90 x H90 mm
JAW Ø140 x H50 mm
Ø140 x H90 mm
Program Ø34 mm Ø60 mm Ø90 mm Ø140 mm
NOSE Ø60 x H60 mm
SINUS Ø90 x H90 mm Ø140 x H90 mm
AIRWAYS Ø60 x H60 mm
MIDDLE EAR Ø34 x H42 mm Ø60 x H60 mm
TEMPORAL
BONE
Ø60 x H60 mm
VERTEBRAE Ø60 x H60 mm

Planmeca ProMax 3D Plus Specifications

General

Imaging Technology	Cone Beam Computed Tomography (CBCT)
Dimensions	varies by configuration
Weight	varies by configuration
Sensor Type	Flat panel detector
CBCT Volume Sizes	Multiple volumes available, ranging from small localized areas to full skull coverage
Voxel Size	75 μm to 400 μm (depending on the resolution mode and volume size)
Radiation Dose	low dose
Software	Planmeca Romexis
X-ray Tube Current	3-15 mA
Detector Type	Flat Panel Detector
Scan Time	varies by scan mode
X-ray Tube Voltage	60-90 kV
