Plas-Ties XL2 - Troubleshooting Solutions Matrix (Part 2)

SECTION V: Troubleshooting
Page 27
CONDITION CAUSE REMEDY
Machine
recycles con-
stantly when
holding in
trigger
switch
a.Control Relay is defec-
tive
a. Replace Control Relay
Ribbon feeds
out constantly
a.LS-3 (Bottom switch) is
not activating on scissor
return
a. Adjust LS-3 arm out-
ward so that LS-2 and
LS-3 activate in close
unison
Main drive mo-
tor M-1 runs
a.Trigger switch (LS-is out
of adjustment
a. Adjust to hear a click
upon releasing of trig-
ger
Depressing trig-
ger has no ef-
fect
a.Trigger switch (LS-1)
out of alignment
b.Safety switch (LS-1) not
closed
c.Fuse blown
a. Adjust to hear a click
upon closing trigger
b. Adjust to hear a click
upon closing cover
c. Check fuse, replace if
necessary
Tie is not
tight
a.Ribbon length is too
short
a. Increase the ribbon
length (see pg. 22-23
Machine will
not cycle
SOLUTIONS MATRIX (cont)
