XL2 SPARE PARTS KIT:

PART# K001021

PART# DESCRIPTION QTY

56903 Miniature Lamp, 120v 1

56909 5 Amp Fuse 2

56922 Power Relay 2

P001570 Micro Switch 4

M021364 Fixed Chute - Wide Mouth 1

M001492 Pinion Shaft Assembly 1

505C127 Gear Segment - Twister Drive 1

505B153 Knife - Ribbon Cutoff 1

M001460 Spring - Tension 1

505B177 Spring - Trigger 1

56602 O’ Ring - Ribbon Forming Lever 16

REPLACEMENT CHAINS

PART#

DESCRIPTION QTY

A401640 16.5” Chain Assembly (for Twister Drive Assembly) 1

A401645 12.5” Chain (for Sliding Plate Assembly) 1

A401630 17.5” Chain Assembly (for Twister Support Assembly: 5 twists only) 1

A401650 13.5” Chain Assembly (for Sprocket Cam Assembly) 1

ITEM#
