SECTION VI: Parts List
Item No. Part No. Description Qty.
5 56715 Screw - Button Head Cap 1/4-20 x .500 1
10 505B184 Stop - Upper 1
15 505R182 Hinged Cover
1
20 M001050 Insulator - Switch 1
25 56501 Nut - Hex 4-40 2
30 56704 Screw - Phillips Head 1/4-20 x .500 4
P001450 Lockwasher - Internal Tooth No. .250 4
35 506358 Capacitor (7.5 mfd) 1
37 56913 Rubber Cover for Capacitor 1
40 16932 Clamp - Metal Capacitor 1
45 56501 Nut - Hex 4-40 2
55 56755 Screw - Pan Head Phillips 10-24 x .500 9
60 M022050 Fixed Cover - Rear 1
65 P001220 Screw - Pan Head Phillips 8-32 x .375 4
70 56823 Axial Fan 1
75 56824 Fan Guard 1
80 56903 Miniature Lamp 1
85 56902 Lamp Holder 1
95 56500 10-32 Kepnet Hex Nut 1
100 P001460 #4 Internal Tooth Lockwasher 2
110 P004364 4-40 x 7/8 Phillips Pan Head Screw 2
115 P004364 4-40 x 7/8 Phillips Pan Head Screw 2
120 P001460 #4 Internal Tooth Lockwasher 2
125 M001200 Switch Spacer 1
130 P001570 Micro Switch 1
135 505B183 Hinge 1
140 506336 10-32 x 3/8 Pan Head Slotted Screw 4
145 56500 10-32 Kepnet Hex Nut 4
150 P001070 Nut - Hex 8-32 1
155 M030000 L Bracket 1
160 506336 10-32 x 3/8 Pan Head Slotted Screw 5
165 P001270 Screw - Pan Head Phillips 8-32 x .500 1
170 P001470 #8 Internal Tooth Lockwasher 1
175 P001580 Circuit Breaker, 115v, 2 amp 1
195 14432 Black Thumb Screw 2
56703 1/4 20 x 1 1/2 Socket Head Cap Screw 2
210 56925 Rocker Switch 1
220 56905 Control Knob 1
To Next Page
