Page 29
SECTION VI: Parts List
Item No. Part No. Description Qty.
225 56908 Fuse Holder 1
230 18034 6/32 x 1/2 Flat Head Screw 2
233 M001040 Counter Seal 1
235 P001760 Counter 1
240 505C225 Front Cover 1
245 16961 6-32 Hex Nut 2
265 P001080 1/4-20 Hex Nut 4
270 505D142 Electrical Chassis 1
275 505B132 Time Delay Relay 1
280 569340 Timer Socket 1
285 506347 Din Rail 1
290 56501 4-40 Hex Nut 1
295 P001460 #4 Lock Washer 1
300 56403 Strain Relief 1
305 56930 8-32 x 3/8 Phillips Sheet Metal Screw 6
310 A301010 Power Cord Assembly 1
315 56960 4-40 x 5/8 Screw 1
325 506336 10-32 x 3/8 Slotted Pan Head Screw 2
330 505C190 Back Cover 1
335 56933 Socket Relay 3
340 56922 Power Relay 3
345 56825 3/8-16 x 2 Shoulder Bolt 1
350 56929 Spring 1
355 505B210 Spring Detent 1
360 M021570 Arm Scissor Actuator 1
365 A202150 Arm Actuator Assembly 1
370 505B114 1/2-13 x 1 1/4 Shoulder Bolt 1/2 Dia. 1
375 56801 # 4 Flat Washer 3
380 56785 5-40 x 3/8 Socket Head Cap screw 1
385 A202120 Rod Scissor Actuator Arm Assembly 1
390 P004150 1/4-28 x 1 Socket Head Cap Screw 1
395 56805 1/4 Split Lock Washer 1
400 505B129 Space - Cutter Cam 1
405 P004858 4-40 x 1 1/4 Phillips Head Screw 2
410 P001460 # 4 Lock Washer 2
415 M001050 Switch Insulator 2
420 M001200 Switch Spacer 1
425 P001570 Micro Switch 2
435 P004706 3/8-16 x 1 Socket Head Cap Screw 4
To Next Page
