Page 30
SECTION VI: Parts List
Item No. Part No. Description Qty.
440 P004715 3/8 Split Washer 4
445 505D173 Frame 1
450 56805 Lock Washer - Internal Tooth No. 250 1
455 1160 1/4-20 x 2 Hex Head Screw 1
460 56802 # 10 Flat Washer 4
465 506337 # 10 Split Lock Washer 4
470 P003420 10-32 x 1 Socket Head Cap Screw 4
475 56738 Screw - Flat Head Socket Cap 10-24 x .500 4
485 M030012 Spacer 2
490 505B155 Guard Ribbon Drive 1
495 56802 # 10 Flat Washer 2
500 P001431 10-24 x 1/2 Flat Hex Socket Screw 2
505 56704 1/4-20 x 1/2 Phillips Pan Head 2
510 A102022 Small Brake Assembly 1
A102021 Large Brake Assembly 1
A102020 Special Brake 1
515 505C166 Right Foot 1
516 56708 1/4-20 x 3/4 Socket Head Cap Screw 4
517 505B163 Leg Frame 4
518 505C164 Back Mounting Plate 1
519 505C165 Left Foot 1
520 P001540 Rubber Foot 4
525 56710 10-24 x 5/8 Screw 4
530 P001431 10-24 x 1/2 Flat Hex Socket Screw 2
535 56802 # 10 Flat Washer 2
540 M021402 Chain Cover 1
545 M026419 Spacer 2
550 A401650 # 35 Chain 13 1/2" Long 1
555 M021601 Sprocket 1
560 P003540 Screw - Shoulder Bolt 10-24 x .250 Dia x .375Lg 1
570 505B112 5/16 x 1/4 Shoulder Bolt 1
575 M021411 Sprocket 1
580 56715 1/4-20 x 1/2 Hex Button Head Screw 1
595 56724 1/4-20 x 3/4 Hex Flat Head Screw 2
600 505B177 Trigger Spring 1
605 505B013 Trigger Arm 1
610 56715 1/4-20 x 1/2 Hex Button Head Screw 2
615 P001450 1/4 Lock Washer - Internal Tooth 2
625 M022065 Shim Spacer 2
