Page 31
SECTION VI: Parts List
Item No. Part No. Description Qty.
630 56001 Bearing 2
635 56723 1/4-20 5/16 Shoulder Bolt 2
640 505B202 Spacer 2
645 505C105 Cam Scissor Guide 1
650 A202180 Scissor Arm Left Assembly 1
655 505B010 Drag Link 1
670 A202170 Scissor Arm Right Assembly 1
675 P001470 #8 Lock Washer- Internal Tooth 2
680 P001220 8-32 x 3/8 Phillips Head Screw 2
685
CHUTES
505B215 1 1/2 " Chute Optional 1
505B216 2 " Chute Optional 1
505B217 21/2 " Chute Optional 1
505C218 3 " Chute Optional 1
505C219 3 1/2 " Chute Optional 1
505C220 4 " Chute Optional 1
690 M021040 Support Block 1
695 505C103 Scissor Arm Cover 1
700 A202110 Ribbon Lever Assembly 1
705 56712 6-32 x 3/4 Socket Head Cap Screw 4
710 56602 O' Ring 8
715 505M001 Spacer 2
720 56906 Magnet 2
725 506338 10-24 x 7/8 Socket Head Cap Screw 2
730 506337 # 10 Split Washer 4
735 56719 10-24 x 3/4 Hex Socket Head Cap Screw 4
740 505B176 Cam Actuator Bracket 1
745 505B144 Slide Return Plate 1
750 505B180 Lower Stop Plate 1
753 M001880 Cone 1
755 M021369 Twister Shaft 1
760 A202090 Twister Support Assembly 1
765 505B117 Sprocket 1
770 56501 4-40 Hex Nut 2
775 505B122 Twister Chain Guard
1
780 P001570 Micro Switch 1
785 M001200 Insulation Spacer-Switch 1
790 A401640 #25 Chain - 16 1/2 Long 1
795 56802 # 10 Flat Washer 3
