Page 32
SECTION VI: Parts List
Item No. Part No. Description Qty.
800 P001430 Screw - Socket Head Cap 10-24 x 1/2 3
805 M001050 Insulation-Switch 1
810 P004362 4-40x1 Phillips Pan Head 2
815 56960 4-40x5/8 Screw 2
820 56801 # 4 Flat Washer 2
825 56900 Nylon Cable Clamp 2
830 505B019 Support- Twister Drive 2
835 506337 # 10 Split Lock Washer 4
840 56705 10-24 x 1 1/2 Screw 4
845 56914 .005 Shim 4
850 P001020 Bearing - Radial Ball R42RS 2
855 A001741 Twister Sprocket 1
880 56726 1/4-20 Shoulder Bolt 5/16 Dia. 1
885 505B129 Spacer - Cutter 1
890 505B130 Link Cutter Actuator 1
905 M001492 Pinion Shaft Assembly 1
910 P001080 1/4-20 Hex Nut 1
915 56711 1/4-20 x 1 Cup Point Set Screw 1
920 M001484 Spring Tension 1
940 505B133 Connector - Cutter Link 1
945 A202130 Bell Crank Assembly 1
950 56002 Bearing 1
955 P001180 Snap Ring 1
960 56100 3/8-16 x 3/4 Shoulder Bolt 1/2 Dia. 1
965 A202040 Support - Cutter Cam Assembly 1
970 56729 10-24 x 1/2 Flat Hex Socket Screw 3
975 56729 10-24 x 1/2 Flat Hex Socket Screw 3
980 505C127 Gear Segment 1
985 505B012M Cam Actuator 1
990 506337 # 10 Split Washer 3
995 56506 10-24 Hex Nut 3
1000 56959 Bodine Motor 1
1005 56503 1/4-28 Hex Nut 1
1010 56805 1/4 Split Washer 1
1015 A302050 Ribbon Feed Wheel Assembly 1
1020 56719 10-24 x 3/4 Hex Socket Head Screw 2
1025 506337 # 10 Split Washer 2
1030 505B168 Cover 1
