Page 35
ASSEMBLIES
Part No. Description Qty.
A202150 Arm Actuator Assembly
505C209 Actuator Scissor Arm 1
56200 Bushing 1
56201 Bushing 1
A202060 Scissor Arm Actuator Assembly
M021570 Scissor Arm Assembly 1
M021540 Pin 1
A302070 Plate, Ribbon Feed Assembly
505D157 Plate, Mounting Ribbon Guide 1
505B201 Receiver Ribbon Drive Wheel 1
56005 Bearing 2
A302060 Ribbon Idler Wheel Assembly
505B198 Wheel Pressure Ribbon Drive 1
56006 Bearing 1
A302020 Lever Assembly Ribbon Wheel
505B149 Shaft, Ribbon Idler 1
505B150 Support Idler 1
A302080 Idler Lock Out Cam Assembly
505B170 Cam, Pressure Wheel 1
56910 1/8 x 1 Roll Pin 2
A301010 Power Cord Assembly
P001610 Power Cord, Black 1
P001410 Connector, Quick Disconnect 1
P001420 Terminal Ring Tongue 1
P001670 Terminal , Male 1
P001690 Connector Receptacle 1
56403 Strain Relief Connector 1
A401675 Electrical Harness Assembly
506340 Timer Socket 1
56933 Socket Relay 3
56931 Metal Jumpers 4
505B132 Time Delay Relay 1
56952 Fork Terminal, Pink 22
P003980 Fork Terminal, Blue 4
56922 Relay, Power 3
56822 Relay Clips 3
P001890 Connector, Plug 3
P001690 Connector, Receptacle Male 3
P003920 Receptacle, With Ears 1
506347 Din Rail 1
