Page 39
APPENDIX B
ELECTRICAL SYSTEM PARTS LIST
INDEX #
PART# DESCRIPTION QTY
1
50641 Capacitor 1
56913 Capacitor Cover* 1
16932 Capacitor Clamp* 1
2
505B222 Track, Mounting* 1
3
56933 Socket, Relay #RS-8 3
4
56922 Relay (115V) GV-DPDT-115A (K1, K2, K3) 3
56822 Relay Clips* 1
5
506340 Socket, Timer 1
6
505B132 Relay, Time Delay (115V) 1
56403
Strain Relief*
1
6A
Part of 6 Potentiometer for Time Delay Relay (R1) 1
56905 Knob #409-D2-K1* 1
7
56908 Fuse holder #342028* 1
56909 Fuse (15V) AGC-5* (F1) 1
16912 A.C. Cord* 1
9
56924 On/Off Switch and Lamp (S1 and L1)* 1
56970 Optional Food Activated Switch* 1
10
505D142 Control Box Chassis 1
505C190 Cover, Back* 1
505C225 Cover, Front* 1
11
16953 Circuit Breaker 1.5 Amp* (CB1) 1
12
16907 Microswitch (LS1, LS2, LS3, LS4) 1
13
56926 Main Motor (M1) 1
505B172 Main Motor Sprocket 1
56928 Transformer #GSD-350 (230V) Options 2
14
505C027-1 Ribbon Feed Motor (m2) 1
505B158 Sprocket Ribbon Feed Wheel 1
505B228 Sprocket 1
*Denotes not shown.
LS4 is located on left side of enclosure, in front & under enclosure lid.
